The Agappe Mispa i2 is a patented, compact specific protein analyzer designed to offer high precision and speed for specialized protein estimations. Utilizing a unique combination of nephelometry and turbidimetry, it provides laboratories with an efficient, reliable solution for processing immununoassay profiles with minimized reagent consumption.
Technical Specifications & Performance
Automation Level: Semi-automated specific protein immunoassay analyzer.
Throughput & Efficiency: Fast testing turn-around times optimized by a smart card calibration system that eliminates the need for manual multi-point calibration curves, reducing reagent waste.
No. of Parameters: Wide menu of specific protein assays including HbA1c, CRP, ASO, RF, IgA, IgG, IgM, C3, C4, Microalbumin, and D-Dimer.
Optical System & Principle: Dual technology featuring Nephelometry and Turbidimetry; equipped with a high-intensity Laser LED light source (650 nm, 5mW) and dedicated laser photo detectors.
Mixing & Incubation: Features automatic mixing driven by an internal motor and a dry heating temperature control system stabilized at 37°C.
Calibration Mode: Pre-calibrated test profiles via a dedicated Smart Card reader system for instant, hassle-free lot updates.
Display: 128 x 64 Graphical Display providing clear user instructions and real-time step-by-step visual guidance.
Interface & Keyboard: Equipped with a 21-key numeric and functional physical keyboard, an RS 232 PC interface port, and support for an optional hand-held barcode reader.
Data Printing: Inbuilt thermal graphical printer for instant documentation of test reports.
