The Agappe Mispa Plus is an advanced semi-automated clinical chemistry analyzer that combines high precision with an intuitive user experience. It features an intelligent touch screen interface and specialized optical technology designed to provide reliable, stable results for routine laboratory biochemistry testing.
Throughput & Efficiency: High operational productivity powered by an Energy Matched Filter (EMF) system for optimal light stability and accurate absorbance readings.
No. of Parameters: 300 unique test programs with massive memory storage for up to 5,000 patient test results.
Optical System & Principle: Photometric module with a long-life halogen lamp (12V/20W), Silicon Photo Diode detection, and 7 standard interference filters (340, 405, 505, 546, 578, 620, and 670 nm) plus 1 optional position.
Analysis Mode: Comprehensive testing methods including 1-Point Linear/Non-Linear, 2-Point Linear/Non-Linear, Kinetic Linear/Non-Linear, Absorbance, Immunoturbidimetry, and Bio-chromatic.
Aspiration & Flow Cell System: Dual-testing capability supporting both a high-grade 30 microliter Quartz flow cell and a direct cuvette mode, driven by a precise peristaltic pump with a programmable aspiration volume from 200 to 999 microliters.
Temperature Control: Peltier-controlled incubation offering stable temperature settings at 25°C, 30°C, 37°C, and room temperature options.
Calibration Curve: Supports highly customizable multi-point calibration up to 9 points on both linear and log scales.
Quality Control: Comprehensive built-in QC program with daily and monthly Levey-Jennings (L-J) chart visualization for reliable result tracking.
Display: Large 7-inch TFT color LCD capacitive touch screen that provides an interactive, modern user interface.
Operating System & Interface: Linux-based embedded operating system featuring direct one-touch access to test menus, an alphanumeric keypad, and an integrated thermal printer with customizable printing options.
