Agappe Mispa Viva Semi-Automated Biochemistry Analyser

The Agappe Mispa Viva is a compact, simple, and reliable semi-automated biochemistry analyzer designed for high efficiency in laboratories. It is capable of performing tests on whole blood, serum, plasma, cerebrospinal fluid, and urine.

Technical Specifications & Performance

• Automation Level: Semi-Automated Clinical Chemistry Analyser.
• Throughput: High efficiency optimized by an Energy Matched Filter (EMF) that ensures stable light intensity for accurate results.
• No. of Parameters: 200 defined programs with storage for 5000 test results and 18000 control results.
• Principle: Photometric module using Silicon Photo Diode detectors and 6 interference filters (340, 405, 505, 546, 578, and 630 nm).
• Analysis Mode: 1-Point, 2-Point, Rate (linear & non-linear), Absorbance, Immunoturbidimetry, Bichromatic, and Kinetic modes.
• Calibration Curve: Up to 9 calibration points and 3 replicates per point using linear and log axes.
• Display: 5.7" TFT LCD color touch screen with popup key pad and 120 x 92 mm view area.
• Operating System: Embedded system with user-friendly software and direct access keys to the test menu.

Physical Specifications

• Dimensions: 362 x 364 x 195 mm (L x W x H).
• Weight: 6 kg.
